Arrow Series Rental Screen

DESIGN CONCEPT
Specially-designed strong cabinet and 2 side fast lock ensure the alignment

INNOVATIVE DESIGN
The cabinet is very strong and easy to handle and climb which makes the fix and unfix much easier
Mechanical design has an air of strongness and simplicity
2 side fast lock ensure the flatness and perfect alignment
LCD indicator to display the status of cabinet including voltage,temperature, working time etc

HIGH REFRESH RATE

1920Hz with MBI5124, 3840Hz with MBI5153.

HIGH CONTRAST

Matt-mask design to make sure the high gray-contrast

WIDE VIEWING ANGLE

Ensure the wide viewangle angle by tracking strictly on production process control and using good led

QUALITY PICTURE

Moire free under camera, you aways get quality picture whenever you shoot

FRONT AND REAR SERVICE AVAILABLE
Front & Rear service both available design offers more flexibility for installation and maintenance

INNOVATIVE DESIGN
Scenico offer all 500*500mm rental cabinet with front and rear service options
They design allows you to use the led screen for both rental application and fixed installation

NOISE FREE

Each individual module stores calibration and operating parameters separately. With a push-out module and identical design, maintenance is a breeze.

CONCAVE AND CONVEX SCREEN IS AVAILABLE

Flat and curve fat lock are both compatible on the same cabinet

PRODUCT PARAMETERS

Technical Parameters
Pixel Pitch	2.6mm	2.97mm	3.91mm	4.81mm
Pixel density	147456	112896	65409	43222
LED Type	SMD2121	SMD2121	SMD2121	SMD3528
Brightness	800nits	800nits	1000nits	1200nits
Gray Scale	16bit	16bit	16bit	16bit
Average Power consumption	180 W/㎡	150 W/㎡	180 W/㎡	150 W/㎡
View Angle	Horizontal 140° Vertical 140°	Horizontal 140° Vertical 140°	Horizontal 140° Vertical 140°	Horizontal 140° Vertical 140°
Refresh Rate	≥1200Hz	≥1200Hz	≥1200Hz	≥1200Hz
Module Size	250x250mm
Cabinet Size	500x500mm
Cabinet Area	0.25m2
Cabinet Material	Die-cast aluminum
Cabinet weight	7.5kg
